POWER PANEL SFX135 SOLAR MODULE

EXTREMELY ROBUST

WITH ETFE COATING

FIBER- 6 m
135 EXTREME GLASS SUN ETFE- CABLE
WATT ROBUST CARRIER- POWER COVERED 2x 2,5
PLATE CELLS mm²
• Very resistant thanks to ETFE front and back foil
with welded outer edges
•SUNPOWER high performance cells
•Compact connection box
•6 m cable (2 x 2.5 mm²) pre-installed
The 135 W Power Panel SFX135 is a semi-flexible solar module with a
new material composition. The SUNPOWER high-performance cells Fiberglass Sheet, ETFE Jacketed
are mounted on a stable, black fiberglass carrier plate, which is
covered by an extremely resistant ETFE layer. This ETFE film is on both
the front and back of the module and is welded together at the edge.
This design ensures optimal protection of the internal cells and makes
the Power Panel SFX135 extremely robust against scratches, heat,
high humidity as well as sea and salt water.

SUNPOWER cells
Power / Sunpower cell count 135 W/36 cells
Material top layer front and back ETFE Structure of the Power Panel SFX135
Material carrier plate Fiberglass (black)
Cell efficiency 24,40 %
Short circuit current (Isc) 6,42 A
Open circuit voltage (Voc) 26.2 Volt
Rated voltage (Vmp) 22,3 Volt Compact connection box (H: 22 mm)
Rated current (Imp) 6,06 A
Dims. mm LxWxH 1235 x 540 x 4
(height connection box) (approx. 22) Top layer
2
Cable (2 x 2.5mm ) 6 m and back made
Weight incl. cable approx. 4.7 kg of ETFE
Item no. 84031 SUNPOWER solar cells
Price 449,-- 6m connection cable pre-assembled Black fiberglass support plate

POWER PANEL SFX135 COMPLETE SET

6 m
135 INCL. MPPT CABLE
CHARGE
CON-
WATT TROLLER 2x 2,5
mm²
• Set includes solar module SFX135 with pre-installed cable
(length 6 m), high-quality MPPT charge controller, roof bushing
• MPPT solar controller (12V/12A, max. 165W) for charging GEL,
lead-acid, AGM and LiFePO4 batteries (battery type adjustable)

Solar panel 1 x 84031 Including MPPT solar Optional accessories
Dims. mm LxWxH (Box H) 1235x540x4 (app. 22) charge controller,
roof cable entry
Cable (2 x 2.5mm ) 6 m and solar cable a
2
MPPT solar charge controller 851005
Controller power 12V/12A, max. 165 W
Cable gland 85258 b
Item no. 85279
Price 549,--

Optional accessories:
a Bluetooth module for MPPT solar charge controller 851005
Display of relevant solar data on the smartphone via Bluetooth.
Cable length: 3 m. 851007 29,90
b Temperature sensor with 3 m cable
851004 10,30
