Page 20 - CARBEST 2024 EN
P. 20

THE COMPACT INTELLIGENT


                                      4 A                    CHARGER WITH 4 A
                                                     IP65


                                                              • LCD display
                                                              • Diagnostic & revival function
                                                              • For 6/12V batteries (AGM, gel, wet)
                                                              • 5 stage charging program
                                                              • Controlled conservation charge
                                                              Microprocessor-controlled charger with 4 A charging capacity. Technical data:
                                                              Protection class IP65, battery capacity: max. 120 Ah. Input voltage: 220-240 V
                                                              AC/ 50 Hz, max. 70 W. Output voltage: max. 14.7 V DC/4.0 A.  Dimensions:
                                                              LxWxH 18 x 8 x 5 cm. Weight: 0.5 kg.   819010  30,56



                                                              CHARGING DEVICES

                                                              WITH 10 A OR 20 A

            10 A                                                                  BATTERY
                                                                             3
                                                                12V   10 A  STEPS  TYPE  ALSO FOR
                                                                                         LiFePO4
                                                                      20 A  CHARGE  SELECTA-  BATTERIES
                                                                                   BLE
                                                               For charging GEL / AGM / lead-acid / LiFePO4 batteries. Battery type selec-
                                                               table via rotary switch. 3 stage charging program with short circuit, overchar-
                                                               ging, reverse polarity and overheating protection.
                                                               Input voltage: 180-240 V AC, Output voltage: Max. 14.6 V DC.
                                                               Incl. Connection cable and battery terminals.
                  20 A                                         Charger 10 A, weight approx. 0.9 kg.
                                                               Dimensions: LxWxH 150 x 130 x 50 mm    80280  89,90
                                                               Charger 20 A, Weight approx. 1.3 kg.
                                                               Dimensions: LxWxH 160 x 150 x 70 mm   80281  129,90





                                                              INTELLIGENT
                                                              PROFESSIONAL CHARGERS
                            a
                            10 A                              WITH THE LATEST 7 STAGE
                                                              CHARGING TECHNOLOGY


                                                                             7
                                                               12V   10-40  STEPS  BATTERY  ALSO FOR
                                                                                  TYPE
                                                                                        LiFePO4
      b                                                               A    CHARGE  SELECTA-  BATTERIES  ECE R10
                                                                                   BLE
     15 A
                                                         c    • For charging gel / AGM / lead-acid / LiFePO4 batteries
                                                              • 2 charging outputs 12V
                                                        20 A
                                                              • The automatic 7 stage charging algorithm delivers a much faster,
                                                               more efficient and more complete charge without voltage drops
                                                               occurring
                                                              • This intelligent battery charger can be used as a constant power
                                                               supply for accessories that need a stable and clean DC voltage
                                                              •  Device cooling via integrated fan
       d
      40 A

                                                               Product   Battery   Connection  Dimensions   kg   Item   Price
                                                                       capacity  cable  (mm)    app.  no.
                                                               a 10 A  15-100 Ah  4 mm 2  176x175x95  1,3  80286  129,--
                                                               b 15 A  20-150 Ah  4 mm 2  176x175x95  1,3  80287  189,--
                                                               c 20 A  25-200 Ah  4 mm 2  176x175x95  1,3  80288  219,--
                                                               d 40 A  50-400 Ah  10 mm 2  276x175x95  3,0  80289  329,--

     20  www.carbest.de
