3-POINT BELT SUPPORT FOR DUCATO, BOXER,

Universal harness blocks for 2 persons 200 mm 200 mm

Tested in the vehicle (homologation) for Fiat Ducato and similar
vehicles. Tested in the vehicle according to ECE R14.06/07.
An acceptance at the TÜV according to § 21 (single acceptance) Suitable for vehicles regis-
is necessary. A prior clarification of the mounting situation in the tered as special motorhome.
vehicle with the TÜV is recommended. Tested in the vehicle accord-
The belt supports are positioned on the side member of the vehi- ing to ECE R14.06/07. mm
cle, in longitudinal direction the position is variable. They are fas-
tened by means of bolts through the vehicle floor. The weight of mm 1199.5
the belt trestle without fastening parts is in each case between
12.5 and 13.5 kg. 1264.5 or
Delivery in each case complete with fastening material and 1116.5
safety belts
800 mm
There are 3 different basic types: 800 mm
Type 1: For Fiat Ducato X250/X290
panel vans/station wagons:
Seatbelt kit normal 59101 526,90
Type 2: For Fiat Ducato X250/X290
chassis with high ladder frame:
Belt support kit normal 59103 564,50
Belt support kit raised (83 mm higher) 59515 543,50
Type 3: For Fiat Ducato X250/X290 mm
chassis with flat frame: 390 390 mm
Belt support kit normal 59102 554,50
Belt support kit raised (83 mm higher) 59516 570,90

Suitable accessories

Headrest Kit
Scope of delivery: 2 curved headrests including
mounting plate 595008 296,99
Isofix mount
For normal belt mounts 59536 156,20
For elevated belt supports 59531 142,--

Belt buck for Ducato,
Boxer, Jumper Tested Tested on the rigid plate
according to according to regulation
Motorhome 76/115 status 96/38
• For retrofitting in motorhomes and 2005/41.
Fiat Ducato, Peugeot Boxer, cm Acceptance according to
Citroën Jumper 107,5 § 21 (individual accept- cm
• With automatic 3-point seat belts
(suitable for child seat) 112
• Belts are concealed in the column,
no twisting possible
• Cantilever construction without cm
cross braces preserves storage cm
space in the stowage box 35 21
• Tested in accordance with applic-
able EC directives on rigid plate 88 or 99 cm
• Previous seat continues to be used, 56 cm 85 cm 65 cm
installation requires registration Divano 505 base,
• With expert opinion for M1 motor- Dimensions: W 99 x D 56 x H 107.5 cm, incl. 2x 3 point safety belt
homes: Acceptance according to § Seat height without support: 35 cm,
21 necessary. Weight approx. 4 kg 59560 899,-- For floor fixing 5 pcs hexagonal bolts
• Fastening to the vehicle floor: Not Dimensions: W 88 x D 56 x H 107,5 cm, M12 UNI5739 are recommended.
included in the scope of delivery. Seat height without support: 35 cm Seat height without support: 21 cm,
(Please clarify installation with your Weight approx. 40 kg 59561 899,-- weight approx. 28,6 kg 615,--
